DIMENSIONS AND WEIGHTS

VEHICLE DIMENSIONS
Load Length 2040
Front Overhang 835
Height 1860
Height (including roof rails) N
Length 4400
Load Deck Height 524
Load Height 1358
Load Space Width Between Wheel Arches 1220
Load Width 1500
Lower Rear Door Width 1262
Rear Door Height 1228
Rear Overhang 840
Side Load Door Height 1171
Side Load Door Width 693
Turning Circle - Kerb to Kerb 10.6
Turning Circle - Wall to Wall 11.1
Upper Rear Door Width 1262
Wheelbase 2725
Width (excluding mirrors) 1695
Width (including mirrors) 2011

WEIGHTS AND CAPACITIES
Gross Train Weight 3100
Gross Vehicle Weight 2000
Load Space Volume 4.2
Max. Towing Weight - Braked 1100
Max. Towing Weight - Unbraked 640
Minimum Kerbweight 1261
No. of Seats 2
Payload 739
Plated 2nd Axle 964
Plated Front Axle 1036

TECHNICAL SPECIFICATIONS

PERFORMANCE
Maximum Speed Mph 98
CO2 mass emissions (Combined) g/Km. 135
Min. Turning Circle (Wall to Wall) m 11.1
Min. Turning Circle (Kerb to Kerb) m 10.6
Engine K9K 1.5dCi
Emissions Euro 5
Seats 2

FUEL TANK
Fuel tank capacity Litres 55

FUEL CONSUMPTION & EMISSIONS
Urban Cycle l/100 Km / MPG 5.7 / 49.6
Extra-Urban l/100 Km / MPG 4.8 / 58.9
Combined l/100 Km / MPG 5.1 / 55.4
CO2 mass emissions (Combined) g/Km. 135

CHASIS
Suspension Front Strut Rear Leaf rigid
Steering Electric Power assisted rack & pinion FUEL TANK
Braking System (option) Disc front, drum rear, ABS, EBD and brake assist
Wheel Size 14°—5.5J FUEL CONSUMPTION & EMISSIONS
Tyre Size 175/70R14C OFFSET 45 P.C.D 114.3°—4H

ENGINE
No. of Cylinders 4
Valves per Cylinder 2
Engine Capacity cm3 1461
Bore x Stroke mm 76.0 x 80.5
Maximum Engine Power hp 89 (66kW) rpm 4000
Maximum Torque Nm 200 rpm 1750
Compression Ratio 18.8
Fuel Type diesel
Fuel Supply commonrail direct injection
Battery 12v Ah 62
Alternator Amps 110/150* * with air conditioning
